Dino-Lite AM7515MT2A

Remarkably compacted with a built-in coaxial light, the 5MP Edge AM7515MT2A delivers exceptional brightfield image at 130-220X magnifications. Through the use of Flexible LEDs Control (FLC), the AM7515MT2A is capable of switching between or mixing brightfield and darkfield for more details.

Brightfield/Darkfield Without the need of other accessories, the brightfield and darkfield illumination can be provided separately or coordinated with each other to explore for more details.

High optical resolution with up to 220X magnifications With superior optics, this Edge model is capable of revealing some of the finest details within a range of 130-220X magnifications.

5.0 Megapixels Thanks to the low loss MJPEG compression, the advanced CMOS image sensor allows to transmit fluid and crisp image with resolution up to 2592x1944.

Automatic Magnification Reading (AMR) Without the hassle to stop and check the magnification for doing a measurement, the AMR detects the magnification rate automatically through the software, making the measurement be a more efficient, accurate, and pleasant process.

Flexible LED Control (FLC) Tasking with software, the FLC maximizes illumination flexibility by offering independent on/off control to the four LED quadrants in addition to the 6-levels intensity adjustment capability.

Scroll Lock The scroll lock ensures the focus knob staying at the desired focus or magnification position without worry of unintentional movement.

Robust housing The metal housing made of aluminum alloy offers compelling advantages of protection and endurance.

Interchangeable caps The interchangeable caps provide adaptability to numerous applications with alternative lighting or object interface, such as but not limited to diffused-light, ring-light, and coaxial-light etc.

Interchangeable front caps   N3C-C / Close Cap   This cap protects the lens and LED lights from contamination of dust, debris, or moisture.   N3C-E / Extended Open Cap   Dino-Lite Edge (stand type) will focus at approximately 200x when the cap touches surface.   N3C-O / Open Cap   This is the standard cap for normal usage.

Information about working distance and field of view M WD FOV (x) FOV (y) DOF 130 4.5 3.0 2.2   140 5.0 2.8 2.1   150 5.6 2.6 1.9   160 6.3 2.4 1.8   170 7.1 2.3 1.7   180 8.0 2.2 1.6   190 8.9 2.1 1.5   200 9.9 2.0 1.5   210 10.9 1.9 1.4   220 11.9 1.8 1.3 0.1 M = magnification rate      WD = working distance (without front cap)      FOV = field of view      DOF= depth of field      Unit = mm
