Dino-Eye AM4023X

by Dino-Lite

Save $225.00

$450.00

$225.00

Quantity

Soon to be Discontinued

The Dino-Eye Premier AM4023X digital eyepiece is a very adaptable digital eyepiece that can fit 23mm, 30mm, and 30.5mm eyepiece slots with its included adapters with its tubular design that is great for setting the right focal point for different types of microscopes. It has a 1.3 megapixel sensor with the ability for long exposures that's great for low light visibility. It allows clear and visible examination of specimens and superb viewing on a computer monitor. The Dino-Eye can be found useful in a laboratory for observation and documentation, a production line for inspection, and much more. In addition to the merit of digitization, the user can find the experience of using a microscope to be more pleasant and comfortable especially for daily microscope users.

Specifications:

Sensor Type	CMOS
Resolution	1280 × 1024 pixels
Megapixels	1.3 MP
Frame Rate (max)	30 FPS
Operating System	Windows XP, Vista, 7, 8, 10, Mac OS 10.5+
Included Software	DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Connection Type	USB 2.0
Image Save Formats (Windows)	BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Image Save Formats (Mac OS)	JPEG, PNG
Video Save Formats (Windows)	WMV, FLV, SWF
Video Save Formats (Mac OS)	MOV

Base Diameter	23mm
Dimensions	8.3cm (L) x 2.5cm (D) (3.27" x 0.98")
Weight	100g (3.5 oz)
Cable Length	182cm (71.65 in)
Body Material	Metal
Measurement	Yes
Package Includes	Camera, Carry Pouch, Software CD, Standard Calibration Target, Adapter (30.5mm), Adapter (30mm)
Warranty Period	2 years
Manufactured in	Taiwan
Service & Support	U.S. (www.dinolite.us) English & Spanish
Regulatory Approval	CE, FCC

Shipping and Handling:
All products purchased from www.microscopes.com.au will be despatched either same day or next day of your order being received. Delivery within Australia can be expected within 7 working days.
